Travel trailer · 2027 model year
2027 Keystone Hideout Mini 166RB specs & floorplan
Explore the 2027 Keystone Hideout Mini 166RB specification sheet: dimensions, weights, sleeping arrangements, tank capacities and available equipment.
Compare this to other models →Source checked 2026-10-19. View manufacturer specifications ↗
© Keystone RV. Illustration may show optional equipment.
At a glance
- Unloaded weight
- 3,090 lb
- Sleeps
- 3
Weight basis: Manufacturer shipping weight.
Dimensions & weights
- Exterior length
- Not verified
- Exterior width
- Not verified
- Exterior height
- 9′ 11″
- Shipping / unloaded weight
- 3,090 lb
- GVWR
- Not verified
- Listed cargo capacity
- 1,295 lb
- Listed hitch weight
- 385 lb
Living & sleeping
- Sleeping capacity
- 3
- Slide-outs
- Not verified
- Main bed
- Queen (size not published)
- Bunk beds
- No
- Dinette
- Not verified
- Bathroom
- Rear bathroom (fixtures not verified)
- Refrigerator
- 3.3 Cu. Ft. 12V refrigerator
Tanks & everyday features
- Fresh water
- 21 gal
- Gray water
- 34 gal
- Black water
- 34 gal
- Awning length
- Not verified
- Shore power / electrical service
- Not verified
- Solar equipment
- SolarFlex™ ready solar prep
- Outdoor kitchen
- No
- Washer/dryer prep
- No
- Microwave
- ✓ Yes
- Cooktop
- 2-burner gas cooktop
- Air conditioning
- 8,000 BTU roof A/C
- Electric fireplace
- No
- Backup camera
- Camera prep (Furrion; camera not included)
- Propane tanks
- 1
- Tire size
- ST205/75R14D
Sources & specification notes
View manufacturer specifications ↗ · Checked .
“Not verified” means a confirmed value is unavailable. “Not listed” does not mean a feature is absent. Optional equipment is not confirmed as installed. Check the exact model year, configuration and unit labels with the manufacturer. This specification sheet does not establish towing compatibility.
How does the 166RB compare?
Add another RV to see the floorplans and specifications side by side.
Compare this to other models →
